8590€
Galvanised steel pool kit
You have just decided to install a pool : our galvanised steel panel pool kits are made for you!
Composition of galvanised in-ground pool kit
Self-supporting pool galvanised steel structure 200/100.
Filtration parts and accessories
(specifically designed panels that do not touch the pool self-supporting structure)
- High water flow skimmer
- Large skimmer inlet
- Discharge nozzles
- Brush adaptor
- Main bottom drain
- 300 W lighting projectors
Filtration parts and accessories
(specifically designed panels that do not touch the pool self-supporting structure)
- High water flow skimmer
- Large skimmer inlet
- Discharge nozzles
- Brush adaptor
- Main bottom drain
- 300 W lighting projectors
| Pool dimensions | 7 x 3,5m | 8 x 4m | 9 x 4,5m | 10 x 5m | 11 x 5,5m | 12 x 6m |
| Number of skimmers | 1 | 1 | 2 | 2 | 2 | 2 |
| Number of discharge nozzles | 2 | 2 | 2 | 3 | 3 | 3 |
| Brush adaptor | 1 | 1 | 1 | 1 | 1 | 1 |
| [noir:Main bottom drain | 1 | 1 | 1 | 1 | 1 | 1 |
| Number of projectors | 1 | 1 | 1 | 1 | 2 | 2 |
Galvanised steel structure
Self supporting structure in galvanised steel, thickness 200/100th, made in france (25 year gaurarentee against perforation).
Panel height 110cm or 150cm, inserts for sealing parts pre-cut by manufacturer.
ADVANTAGES OF GALVANISED STEEL
Galvanised steel is renowned for its properties of remarkable mechanical strength and is the reason why this material is used in many sectors of the construction industry.
This material is robust and malleable and offers an excellent protection against corrosion. Galvanised steel is often chosen as the construction material used to build supporting frames of bridges, tunnels and buildings.
Panel height 110cm or 150cm, inserts for sealing parts pre-cut by manufacturer.
ADVANTAGES OF GALVANISED STEEL
Galvanised steel is renowned for its properties of remarkable mechanical strength and is the reason why this material is used in many sectors of the construction industry.
This material is robust and malleable and offers an excellent protection against corrosion. Galvanised steel is often chosen as the construction material used to build supporting frames of bridges, tunnels and buildings.
The galvanised steel panels used in our kits give an outstanding resistance, allowing installation in all stabilized soils.
Our metallic kits are designed using a hot-dip galvanization process, ensuring a long lifespan and exception protection against corrosion. The structure is guaranteed for 25 years against rust perforation.
SELF SUPPORTING STRUCTURE
The structure is constituted using galvanised steel, self-supporting panels. The panels are capable of resisting the pressure of water, without the necessity of completing a landfill around the parameter of the structure. The panels are also totally secure when emptying the pool as the panels support the weight of the surrounding earth.
Installed with ease, you can totally landfill around the pool, install the pool border or add on peripheric borders. You can also envisage a pool design partially in-ground and partially above ground, with no difficulty regarding water pressure resistance.
Panels
Galvanised steel
Height of panels
110cm or 150cm
Structure of panels
6 fold, ensuring pressure resistance and maximum rigidity
Sealing parts insertion
Pre-cut by manufacturer
Supporting legs
Angled steel
Assembly nuts and bolts
Galvanised
Detailed view of the swimming pool
Detailed view of pool structure
1. Galvanised steel panel structure
2. Supporting legs
3. Concrete sealing of supporting leg
4. Peripheric chaining supporting pool border (peripheric concrete beam + reinforcing bars)
5. Reinforcing bars
6. Support plot (concrete block structure)
Main stages of your pool installation:
Following landscaping, the structure is assembled, positioned, and levelled. Then sealing is then completed with concrete mixed to 350kg.
The pool floor screed is completed in the pools interior. Filtration parts are positioned and plumbing work is carried out.
The supporting plots needed to install the peripheric chaining is completed. Landfill surrounding the panels and position the liner rail. Complete the peripheric chaining. Install the pool border. Install the pool floor underfelt followed by the pool liner. Fill with water.
1. Galvanised steel panel structure
2. Supporting legs
3. Concrete sealing of supporting leg
4. Peripheric chaining supporting pool border (peripheric concrete beam + reinforcing bars)
5. Reinforcing bars
6. Support plot (concrete block structure)
Main stages of your pool installation:
Following landscaping, the structure is assembled, positioned, and levelled. Then sealing is then completed with concrete mixed to 350kg.
The pool floor screed is completed in the pools interior. Filtration parts are positioned and plumbing work is carried out.
The supporting plots needed to install the peripheric chaining is completed. Landfill surrounding the panels and position the liner rail. Complete the peripheric chaining. Install the pool border. Install the pool floor underfelt followed by the pool liner. Fill with water.
The filtration of your pool
Our galvanised steel pool kits are available with a choice of two water filtration systems.
An outboard filtration systems means you do not require a technical shelter or underground service piping and you do not put residual chemical waste back into the water system. Practical, this system limits installation work.
A traditional filtration system is composed of a sand filter, a self-priming pump, and electrical distribution box with cables, various valves, collectors and u-bends, PVC piping and PVC glue. This evolving system is more economical when purchasing, and all the material is contained on one, protected transportation palette.
Filtration monobloc, without technical shelter
A. Removable lid with locking function
B. Electrical box + Programmation control
C. Filter pump
D. Two removable filter cartridges with collector baskets.
E. Balneotherapy (Air regulator knob).
F. Skimmers, two openings creating suction inlet.
G. Adjustable discharge nozzle
H. LED lighting feature
Filtration pump with a motor capacity of 1,1kW
Water flow 12 to 25m³/h (depending on model)
Featuring two removable polyester filter cartridges
Filter surface 4,5 to 9m2 (depending on model)
Filter capacity 25 microns
Bodywork ABS – PMMA thermoformed
Security overflow
Electrical distribution box with circuit breaker
To learn more please consult Filtrinov outboard filtration monoblocs
B. Electrical box + Programmation control
C. Filter pump
D. Two removable filter cartridges with collector baskets.
E. Balneotherapy (Air regulator knob).
F. Skimmers, two openings creating suction inlet.
G. Adjustable discharge nozzle
H. LED lighting feature
Filtration pump with a motor capacity of 1,1kW
Water flow 12 to 25m³/h (depending on model)
Featuring two removable polyester filter cartridges
Filter surface 4,5 to 9m2 (depending on model)
Filter capacity 25 microns
Bodywork ABS – PMMA thermoformed
Security overflow
Electrical distribution box with circuit breaker
To learn more please consult Filtrinov outboard filtration monoblocs
Classic filtration system using a sand pre-filter
Self-priming filter pump
Horsepower 3/4hp to 1,5hp (depending on model)
Water flow from 10 to 21m3/h (depending on model)
Compatible with electrolysis water treatment systems
Sand filter
Tamper-resistant plastic, unaltered by contact with chemical agents and atmospheric conditions
Diameter 48 to 75cm depending on model
6-way selection valve
Simplified closing system
We recommend Fibalon filtration substance, available on option FIBALON® replaces the sand or cartridge of your pool filter
Electrical distribution box and cables
Protection index IP 55
With fuse, timeclock and thermomagnetic circuit breaker
Transformer 220v/12v
Power contactor
For pump and projector(s)
Sealed parts
Skimmer
2 discharge nozzles
Main water drain
Brush adaptor
Projector
Plumbing
PVC kit includes :
- ¼ turn valves
- U-bends
- T connections
- Union connections
- Rigid PVC bars resistant to 16 bars
- Glue
- Stripper
- Sealing compound
Horsepower 3/4hp to 1,5hp (depending on model)
Water flow from 10 to 21m3/h (depending on model)
Compatible with electrolysis water treatment systems
Sand filter
Tamper-resistant plastic, unaltered by contact with chemical agents and atmospheric conditions
Diameter 48 to 75cm depending on model
6-way selection valve
Simplified closing system
We recommend Fibalon filtration substance, available on option FIBALON® replaces the sand or cartridge of your pool filter
Electrical distribution box and cables
Protection index IP 55
With fuse, timeclock and thermomagnetic circuit breaker
Transformer 220v/12v
Power contactor
For pump and projector(s)
Sealed parts
Skimmer
2 discharge nozzles
Main water drain
Brush adaptor
Projector
Plumbing
PVC kit includes :
- ¼ turn valves
- U-bends
- T connections
- Union connections
- Rigid PVC bars resistant to 16 bars
- Glue
- Stripper
- Sealing compound
Composition of Kit
Liner
Uniform liner, 75/100 made to measure, guaranteed for 10 years, (digressively concerning welded points), 7 standard colours (border or impression available on option).
Liner rail "Hung" using self-piercing screws. Pool floor anti-rotting underfelt 350 g/m2, supplied with specific glue.
Important : it is indispensable to check the installed pool dimensions before ordering your liner
Available colours
 Anthracite ALKORPLAN 2010 |  White |  Blue France |  Pale blue |
  Grey ALKORPLAN 2010 |  Sand |  Byzantin blue |  Byzantin green |
 Persian blue |  Persian blue grey |  Persian green |  Persia old rose |
 Marble blue |  Marbre grey |  Marble sand |
Borders
PVC borders welded by high frequency available on option with your choice of standard liner. Their dimensions are 240mm in height.
 Carthage blue |  Carthage green |  Genova grey blue |  Florentine grey blue |
 Olympia blue |  Olympia green |  Oxford blue |  Oxford grey blue |
 Mallorca blue |  Mallorca sand |
Sealing parts
Installation system
The panels are precut by the manufacturer taking into account the position and dimensions of the sealed filtration equipment such as the skimmer, the discharge nozzles, brush adaptor and projector(s).
This system is totally specific to an aquatic environment and ensures that water is not in contact with the steel panels.
The sealed parts overlap the pool structure, ensuring no contact between the pool water and the pool structure.
The panels are precut by the manufacturer taking into account the position and dimensions of the sealed filtration equipment such as the skimmer, the discharge nozzles, brush adaptor and projector(s).
This system is totally specific to an aquatic environment and ensures that water is not in contact with the steel panels.
The sealed parts overlap the pool structure, ensuring no contact between the pool water and the pool structure.
Detailed view of the discharge nozzle
1. Skimmer
Elegance 400 from WELTICO has a modern, elegant design. The skimmer features a wide water inlet (opening 200 x 400) and is equipped with an outlet connection that links a water level regulator is desired (available on option).
2. Brush adaptor
PVC ASTRAL POOL complete with o-rings, sealing clamp and screws. Diameter 50mm.
3. Discharge nozzle
PVC ASTRAL POOL with adjustable ball joint and adjustable diameter of discharge. This equipment ensures the return of filtered, treated water to your pool.
4. Main bottom drain
5. Projector
Projector 300 W/ 12V and its connection box.
Maintainance
Cleaning kit
Brush head
Telescopic handle
Floating pipe
Cleaning net
Test pouch
- Excavation plan (must be scrupulously respected)
- Installation guide
- Maintainance and use guide
- Helpline
Brush head
Telescopic handle
Floating pipe
Cleaning net
Test pouch
Various
- Excavation plan (must be scrupulously respected)
- Installation guide
- Maintainance and use guide
- Helpline
Ladder 3 step stainless steel with anchoring plates
Step option
DOM COMPOSIT reinforced acrylic
To facilitate access to the pool and create a relaxation zone, the step designed in DOM COMPOSIT reinforced acrylic is the ideal solution. You can position your steps on the length, width or corner angle of your pool.
Easy to install, the step module takes the place of one or several panels of the pool structure. The liner is clamped on the front of the steps, avoiding un-esthetic folds and a slipping hazard.
Reinforced acrylic indicates the steps are very resistant, do not scratch, do not chip and are not affected by varying temperatures, chlorine or UV. An anti-slipping treatment is applied to the steps and is tinted in the mass.
The steps are supplied with a spare discharge nozzle and have a 10-year guarantee. The step option cancels the supplied ladder.
The choice of 6 colours can adapt to the majority of pool liners.
Available colours
Light blue
Sand
Azur blue
White
Carribian green
Grey
We can supply steps with various colours, dimensions and heights, so you can find the perfect solution to fit your operational and esthetic pool criteria.
To find out more about our range of Dom Composit products click on the following link:
DOM COMPOSIT acrylic steps
Installation
Installation guide for pool kit
Reminder of pool kit prices
| Rectangular pool kit, height, 1,10m, choice of floor type | Price inc. VAT | Rectangular pool kit, height, 1,50m, flat floor | Price inc. VAT |
| Galvanised pool kit 7x3,50m x h1,10m | 5990.00 € | Galvanised steel pool kit 7x3,50m x h1,50m filtration Quick Pack | 6990.00 € |
| Galvanised steel pool kit 8x4m x h1,10m filtration Quick Pack | 6790.00 € | Galvanised steel pool kit 8x4m x h1,50m filtration Quick Pack | 7890.00 € |
| Galvanised steel pool kit 9x4,50m h1,10m | 7590.00 € | Galvanised steel pool kit 9x4,50m h1,50m | 8590.00 € |
| Galvanised steel pool kit 10x5m h1,10m | 8390.00 € | Galvanised steel pool kit 10x5m h1,50m | 9290.00 € |
| Galvanised steel pool kit 11x5,5m h1,10m | 9390.00 € | Galvanised steel pool kit 11x5,5m h1,50m | 10290.00 € |
| Galvanised steel pool kit 12x6m h1,10m | 9990.00 € | Galvanised steel pool kit 12x6m h1,50m | 11590.00 € |
Photos non-contractual
Ask for a free quote galvanised steel pool kit
Other product : Galvanised steel pool kit
Starting from 8590 eur Including VAT.
