Calplas laminated stratified sand filter

The tank of the Calplas sand filter carries a 10-year guarantee proving its dependability and resistance. High-quality materials are used for its manufacture (stratified polyester), and developed methods, including an inner and outer gel coat, ensure this to be a product choice that will remain unaltered with time.

The Calplas is easy to maintain, featuring a closed base, purge and emptying valves. Equally easy to clean because of the inner gel coat gel coat that guarantees an efficient backwash, eliminating all dirt collected during the filtering cycle of your pool water.
Equally equipped with a transparent dome made from methacrylate resin, 200 mm in diameter and closed by bolting. A suporting leg is integrated into the base of the tank and automatic air purge.

Dimensions of the Calplas sand filter

—	D	H	A	B	E	Area filtered (m2)	Water flow (m3/h)	Connections	Filter recharge (kg)
103010	640	810	310	500	25	0,30	15	1 1/2" - 50	160
103011	720	910	360	550	75	0,40	20	2" - 63	240
103012	840	930	360	550	75	0,52	30	2" - 63	320
CALC35S	915	1005	445	695	120	0,70	35	2 1/2" - 75	500
